AMI DARK|SKY

About DARK|SKY

AMI DARK|SKY is an astro|photography club that meets on select post-COVID nights under the clear, new moon, Bortle Class 5 skies of Denville. AMI members and incoming initiates are welcome to join Morris Catholic faculty from multiple departments as they tinker with photographic gear mated to astronomical toys.
DARK|SKY Calendar Events

2 September 2021 | Impromptu meet with about 7 telescopes and a star-studded cast (get it?): Venus, Saturn, Jupiter (and its moons), Andromeda Galaxy (M31).

24 June 2021 | Finally some decent weather!

*Canceled* 10 May 2021 | New Worm Moon. See below.

*Canceled* 12 April 2021 | New Snow Moon. Bring your own telescopes for the first (hopefully) post-COVID get-together on the Soccer Field at Morris Catholic High School. The event will feature food, Fr. Brian's lavish catadioptric telescope, Dr. Ciar's star-tracker photography rig, and his 10" Dobsonian Telescope. This event is weather-permitting.



Orion Nebula
Figure 1 | The Great Orion Nebula. Located in the constellation of Orion (in the sheath of his sword—for reference, see Figure 2), this famous nebula was photographed on 1/16/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/5.6, and ISO 40,000. The rig was cropped in-camera at 1.6x for a total raw focal length of 640mm. 27x1s images were integrated within DeepSkyStacker and edited in Adobe Photoshop CC v. 22.1.1. The imaging rig was not tracked to a sidereal rate (plain-old tripod! See Figure 3!).

Messier 42
Figure 2 | Location of the Orion Nebula (Messier 42; NGC 1976) some 1,344 light years from Earth. Sources: WikiSky; https://www.messier-objects.com/messier-42-orion-nebula/

Orion 2.0
Orion v3
Figure 3 | The Great Orion Nebula (v. 2.0, top; v. 3.0, bottom). Photographed on 3/2/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 500. The rig was used in full-frame mode for a total raw focal length of 400mm. 188x30s images were integrated within Sequator for a total of 1.6h of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software). The imaging rig was tracked to sidereal rate on a Sky-Watcher Star Adventurer 2i Pro (unlike Figure 1), allowing much longer exposure times.

Horsehead & Running Man
Figure 4 | The Horsehead (Barnard 33) & Flame (NGC 2024) Nebulae. Photographed on 3/13/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 1600 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 400mm. 32x88s images were integrated within Sequator for a total of 47m of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software).

Whirlpool Galaxy
Figure 5 | The Whirlpool Galaxy (M51). Photographed on 4/5/2021 from Middlebury, CT, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 3200 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 400mm. 109x120s images were integrated within Sequator for a total of 3.6h of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).

Pinwheel Galaxy
Figure 6 | The Pinwheel Galaxy (M101). Photographed on 4/7/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 3200 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 400mm. 37x120s images were integrated within Sequator for a total of 1.2h of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).

Cigar & Bode's Galaxies
Figure 7 | Cigar Galaxy (M82, left) and Bode's Galaxy (M81, right). Photographed on 4/8/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 3200 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 400mm. 63x120s images were integrated within Sequator for a total of 2.1h of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).

Quarter Moon
Figure 8 | Quarter Moon. Photographed on 4/20/2021 from Flanders, NJ, using a Canon EOS RP with a 10" Dobsonian telescope through a 25mm Apertura eyepiece. It was a single full-frame exposure for 1/150s on a bare sensor at ISO 100. The raw focal length of the scope was 1250mm. The image was cleaned up in Adobe Lightroom CC.

Hercules Cluster
Figure 9 | The Great Cluster in Hercules (M13). Photographed on 6/28/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens and a 2x Sigma APO Teleconverter at f/8, and ISO 640 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in cropped-sensor mode for a total raw focal length of 640mm. 38x120s images were integrated within Sequator for a total of 76 minutes of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).

NA & Pelican Nebulae
Figure 10 | North America Nebula (NGC 7000 or Caldwell 20) and Pelican Nebula (IC 5070 and IC 5067). Photographed on 6/29/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma EX DG OS 70-200mm f/2.8 lens at f/4, and ISO 800 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 200mm. 74x120s images were integrated within Sequator for a total of 2.5h of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).


Jupiter & Saturn
Figure 11 | Jupiter & Saturn. Photographed on 8/19/2021 from Flanders, NJ, using a Canon EOS RP with a 10" Dobsonian telescope through a 2.5x Celestron Luminos 2" Barlow. Multiple crop-sensor exposures (1/60s on a bare sensor at ISO 800) were processed together using PIPP, Autostakkert, and Adobe Photoshop CC v. 22.1.1. The raw focal length of the scope was 1250mm.


Jupiter #2
Figure 12 | Jupiter. Photographed on 8/21/2021 from Flanders, NJ, using a Canon EOS RP with a 10" Dobsonian telescope through a 2.5x Celestron Luminos 2" Barlow. Multiple crop-sensor exposures (1/60s on a bare sensor at ISO 800) were processed together using PIPP, Autostakkert, and Adobe Photoshop CC v. 22.1.1. The raw focal length of the scope was 1250mm.


Saturn
Figure 13 | Saturn. Photographed on 8/23/2021 from Flanders, NJ, using a Canon EOS RP with a 10" Dobsonian telescope through a 2.5x Celestron Luminos 2" Barlow. Multiple crop-sensor exposures (1/60s on a bare sensor at ISO 800) were processed together using PIPP, Autostakkert, and Adobe Photoshop CC v. 22.1.1. The raw focal length of the scope was 1250mm.


Andromeda v2
Figure 14 | The Andromeda Galaxy (M31). Photographed on 8/24/2021 from Flanders, NJ, using a Canon EOS RP with a Sigma 150-600mm DG OS HSM f/5-6.3 lens at f/6.3, and ISO 400 on a Sky-Watcher Star Adventurer 2i Pro tracking at sidereal rate. The rig was used in full-frame mode for a total raw focal length of 600mm. 24x120s images were integrated within Sequator for a total of 48 min of data; the output TIFF was then stretched in Adobe Photoshop CC v. 22.1.1 using the Astronomy Tools Action Set (v. 1.6.2 from ProDigital Software) and AstroFlat Pro (v. 1.4.11 from ProDigital Software).
